4 Tons Heating / 3.5 Tons Cooling
Stackable up to 35 tons. |
|
Design Options: |
||
CX45 Outdoor Unit (ODU) |
Connect up to 10 indoor units. |
CX45 Cooling Performance:
| System | Test Conditions | Capacity BTU | Power kW | COP | EER |
| CX45 | at A95°/W64º | 49,815 | 3.84 | 3.8 | 12.96 |
| CX45 | at A95°/W54º | 43,571 | 3.56 | 3.56 | 12.15 |
| CX45 | at A95°/W44º | 36,849 | 3.36 | 3.21 | 10.95 |
Learn more about our chiller efficiency and technology.
|
 |
Super quiet low wall or floor unit above. Shown with leg kit below.
 |
The HW72 high-wall fan coil unit looks like a standard mini-split indoor unit. This unit is designed for a chiller, includes remote control. 208-240v 50/60 Hz AC motor.
 |
Chiltrix DC-Inverter Ultra-Thin CX series FCUs are built for universal mounting, they can mount on the ceiling, wall, or floor.
For ducted systems, Chiltrix is compatible with most standard hydronic air handlers. Consult with us for sizing and compatibility.
